TECHNICAL DATA

  • Pressure range : 0-16 bar
  • Temperature range : 0 to 200 deg. C
  • Vacuum resistance: Full vacuum
  • Face to face : ANSI B16.10
  • Flange drilling :ANSI B16.42 / B16.5-150#
  • options : DIN PN 10/16

SALIENT FEATURES

  • Available in Standared Reduced port design with flanged ends.
  • Choice of four different fluoroplastic lining materials to prmide corrosion and temperature resistance for almost all applications.
  • Extra thick locked-in-lining for high vacuum rating (minimum 3mm).
  • Blow-out proof stem.
  • Unique packing system. Self adjusting with permanent loading (Stainless steel Belle,. springs). PTFE chevron packing provide stem seal integrity while maintaining low turning torque.
  • Integrated Actuator mounting: For applications requiring automaric actuation and for manual actuation of large size Valves direct mounting of ISO 5211 compliant quarter turn actuator.
  • External protection against corrosion with epoxy coating, stainless steel fasteners.


OPTIONAL FEATURES

  • Lockable handles: For applications which require protection against inadvertent opening or closing of the levers which can be locked using padlocks can be provided
  • Extended Stem: For applications requiring insulation of the pipe line or for ease of operation, the valves can be supplied with an extended stem, along with an ISO 5211 actuator mounting flange.
